Punch sound box (iron)

Punch sound box (iron)Iron sound box features:Fine structure, Zoran superior, excellent material, reasonable structure, standard standards, color environmental protection, saving space, is the first c

Punch sound box (iron)

Punch sound box (iron)

Iron sound box features:
Fine structure, Zoran superior, excellent material, reasonable structure, standard standards, color environmental protection, saving space, is the first choice for the factory planning equipment.
Modern modeling, unique, material structure is stable and reasonable, Seiko fine build, clean and noble, the concept of environmental protection, is the performance of heavyweight enterprises called the industry and the environment of the first-class combination.
Iron sound box configuration:
    High-speed punch bed front door for the sliding door, the back door and on both sides of the door, front / rear are equipped with noise monitoring window. Left and right side for the activities of the discharge port, with a set of wheel guide (side 4). Low noise in the row
Sound pulley pumping each one. Environmental protection lighting 45W5T fluorescent two sets. Internal power switch socket set. Trademark advertising signs a set (by the customer provider label). Choose advanced ICI
Tensile paint rust treatment (color optional).
 The use of three anti-compliance materials and noise control effect
GB 1.0-2.0mm hot rolled steel plate.
GB 0.6mm × φ3.0mm punching galvanized sheet.
Imported rockwool (100kg / m3 × 50mm) smoke insulation fire protection cotton board.
Import PEF (10mm) resistance to the sound board.
Taiwan plant production (20kg / m3 × 10mm) high-density sublime sound-absorbing foam plate.
The noise effect is 75-80 decibels (single sound source) to the national labor deafness protection regulations

Description: high-speed punch noise box can be made into a noise effect of 50/70 / 100mm three thickness specifications
